Network Modules - Bestsellers
Interface
Profinet / EtherNet/IP
Operating voltage Ub
18...30 VDC
Display
no
Connection (COM 1)
M12x1-Female, 4-pin, D-coded
Connection (COM 2)
M12x1-Female, 4-pin, D-coded
Do you have any questions about the product?
Alternative products
|
Available
|
Alternative
|
|
|
|
|
|
BNI00HRBNI XG1-505-0A5-K0842,673.75 CNY |
BNI00HPBNI XG1-505-0A5-K0832,587.50 CNY |
|
| Interface | Profinet / EtherNet/IP | - |
|---|---|---|
| Operating voltage Ub | 18...30 VDC | 18...30 VDC |
| Display | no | no |
| Connection (COM 1) | M12x1-Female, 4-pin, D-coded | M12x1-Female, 4-pin, D-coded |
| Connection (COM 2) | M12x1-Female, 4-pin, D-coded | M12x1-Female, 4-pin, D-coded |
| Connection (supply voltage IN) | M12x1-Male, 3-pin, L-coded | M12x1-Male, 2-pin, A-coded |
| Connection slots | 8x M12x1-Female, 5-pin, A-coded | 8x M12x1-Female, 5-pin, A-coded |
| Digital inputs | 16x PNP, Type 3 | 16x PNP, Type 3 |
| Digital outputs | 8x PNP | 8x PNP |
| Configurable inputs/outputs | yes | yes |
| Interface IIoT | REST API, MQTT | REST API, MQTT |
| Output current max. | 250 mA short-circuit proof and overload-proof | - |
| Current sum US, sensor | 4.0 A | 4.0 A |
| Housing material | PC, injection molding | PC, injection molding |
| Dimension | 59 x 36.8 x 180 mm | 59 x 36.8 x 180 mm |
| Ambient temperature | -25...55 °C | -25...55 °C |
| IP rating | IP67 | IP67 |
| Auxiliary interfaces | 8x IO-Link | 8x IO-Link |
| IO-Link version | 1.1.3 | 1.1.3 |
| Port-class | Type A | Type A |
