BIS01FW

BIS V-830-3-011-B-001

RFID Handheld Base Unit

Product group
RFID Mobile Devices
Principle of operation
Handheld
Operating system
Android™ 11
Processor
NXP i.MX8M mini
4x Cortex A53 (4x 1,8 GHz)
1x Cortex M4 (1x 400 MHz)
Working memory
2 GB RAM
Do you have any questions about the product?

Quantity scale

Contact request
Key features
Product group
RFID Mobile Devices
Principle of operation
Handheld
Operating system
Android™ 11
Processor
NXP i.MX8M mini
4x Cortex A53 (4x 1,8 GHz)
1x Cortex M4 (1x 400 MHz)
Working memory
2 GB RAM
Data storage
16 GB Flash
Display
5" TFT color display with LED backlight
1280 x 720 pixels, 400 cd/m²
Capacitive touch
Surface hardness 7H
Battery type
Lithium-ion accu
Interface 01
WLAN
Interface 02
Bluetooth
Operating voltage Ub
3.8 VDC Battery pack
Function indicator
Progress indicator, LED
IP rating
IP65
Approval/Conformity
CE
UKCA
cCSAus
FCC (Radio)
IC (Radio)
WEEE
CCC
SRRC
Additional features
Integrated barcode scanner: 1D and 2D short-range scanner integrated in the housing (scanner buttons on the side)
Integrated camera: 5 MP autofocus camera with lighting
Classifications
ECLASS 10.1
27-28-04-92
ECLASS 11.0
27-28-04-92
ECLASS 12.0
27-28-04-92
ECLASS 13.0
27-28-04-92
ECLASS 14.0
27-28-04-92
ECLASS 5.1.4
27-28-90-90
ECLASS 6.2
27-28-90-90
ECLASS 8.1
27-28-04-90
ECLASS 9.0
27-28-04-92
ECLASS 9.1
27-28-04-92
