BIS01FL

Name: BIS01FL
Brand: Balluff
SKU: BIS01FL
Price: 13596 CNY
Availability: OutOfStock

BIS V-6108-048-C102-SA13

Multi-frequency RFID BIS V

Product group

Multi-Frequency Processor

Interface

Profinet I/O (IRT)
2 port Switch

Supported RFID technologies

LF 125 kHz (BIS VL)
LF 70/455 kHz (BIS C )
HF 13.56 MHz (BIS VM)
UHF 860...930 MHz (BIS VU)

Number of connectable R/W heads / antennas

Operating voltage Ub

24 V DC LPS Class 2

Put together your individual RFID system, tailored to your needs and areas of application.

Recommended successor products

Estimated vailability

How does the alternative product differ from the discontinued one?

Do you have any questions about the product?

	Discontinued	Recommended alternative

	BIS01FL BIS V-6108-048-C102-SA13 13,596.00 CNY	BIS013W BIS V-6108-048-C102 13,596.00 CNY
Product group	Multi-Frequency Processor	Multi-Frequency Processor
Interface	Profinet I/O (IRT) 2 port Switch	Profinet I/O (IRT) 2 port Switch
Supported RFID technologies	LF 125 kHz (BIS VL) LF 70/455 kHz (BIS C ) HF 13.56 MHz (BIS VM) UHF 860...930 MHz (BIS VU)	LF 125 kHz (BIS VL) LF 70/455 kHz (BIS C ) HF 13.56 MHz (BIS VM) UHF 860...930 MHz (BIS VU)
Number of connectable R/W heads / antennas	4	4
Operating voltage Ub	24 V DC LPS Class 2	24 V DC SELV/PELV
Housing material	Zinc, Die casting	Zinc, Die casting
Ambient temperature	0...60 °C	0...60 °C
IP rating	IP65, with connector	IP65, with connector
Approval/Conformity	CE UKCA cULus WEEE FCC (Radio) IC (Radio) KC ETA NBTC IFT	CE UKCA cULus WEEE FCC (Radio) IC (Radio) KC ETA NBTC IFT
Connection	2x M12x1-Female, 4-pin, D-coded 7/8"-Male, 5-pin	2x M12x1-Female, 4-pin, D-coded 7/8"-Male, 5-pin
