Alternative products
|
Available
|
Alternative
|
|
|
|
|
BES013HBES M05ED-PSC50F-S26G817.80 CNY |
BES0139BES M05ED-POC50F-S26G817.80 CNY |
|
| Dimension | Ø 5 x 44 mm | Ø 5 x 44 mm |
|---|---|---|
| Style Housing | M5x0.5 | M5x0.5 |
| Installation | non-flush | non-flush |
| Range | 5 mm | 5 mm |
| Switching output | PNP normally open (NO) | PNP normally closed (NC) |
| Switching frequency | 3000 Hz | 3000 Hz |
| Housing material | Stainless steel | Stainless steel |
| Material sensing surface | PET-C | PET-C |
| Connection | Connector, M5x0.5-Male | Connector, M5x0.5-Male |
| Operating voltage Ub | 10...30 VDC | 10...30 VDC |
| Ambient temperature | -25...70 °C | -25...70 °C |
| IP rating | IP67 | IP67 |
| Approval/Conformity |
CE UKCA cULus WEEE |
CE UKCA cULus WEEE |
Only CAD model download is supported
