Similar Illustration

BCC0JJC

Name: BCC0JJC
Brand: Balluff
SKU: BCC0JJC
Price: 931.6 CNY
Availability: OutOfStock

BCC S414-E894-8G-672-ES64N9-100-C009

Chemical resistant cables (stainless)

Connection 1

M12x1-Male, straight, 4-pin, D-coded

Connection 2

RJ45-Male, straight, 4-pin

Interface

Ethernet/IP

Cable

TPE Shielded teal, 10 m, drag chain compatible

Cable, note

Ethernet, CAT 5E

Do you have any questions about the product? Get in touch with us.

This product page contains information for China – Balluff Automation (Shanghai) Co., Ltd

		Alternative	Further alternative

	BCC0JJC	BCC0E8P	BCC0J1R
	BCC S414-E894-8G-672-ES64N9-100-C009	BCC M414-E894-8G-672-ES64N9-100	BCC M414-E894-8G-672-ES24N9-100
	931.60 CNY	883.12 CNY	883.12 CNY

Connection 1	M12x1-Male, straight, 4-pin, D-coded	M12x1-Male, straight, 4-pin, D-coded	M12x1-Male, straight, 4-pin, D-coded
Connection 2	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin
Interface	Ethernet/IP	Ethernet/IP	Ethernet/IP
Cable	TPE Shielded teal, 10 m, drag chain compatible	TPE Shielded teal, 10 m, drag chain compatible	TPE Shielded Red, 10 m, drag chain compatible
Cable, note	Ethernet, CAT 5E	Ethernet, CAT 5E	Ethernet, CAT 5E
Number of conductors	4	4	4
Cable temperature, flexible routing	-40...80 °C	-20...60 °C	-40...80 °C
Operating voltage Ub	60 VDC / 50 VAC	60 VDC	42 VDC / 30 VAC
Rated current (40 °C)	1.0 A	1.5 A	1.0 A
IP rating	IP69K/IP20	IP67/IP20	IP67/IP20
Approval/Conformity	CE cULus WEEE	CE cULus WEEE UKCA	CE cULus WEEE UKCA
Cable temperature, fixed routing	-	-40...80 °C	-
