Alternative products
|
|
Alternative
|
Further alternative
|
|
|
|
|
|
BES00AFBES M30MI-PSC15B-S04G456.45 CNY |
BES00AHBES M30MI-PSC15B-S04K456.45 CNY |
BES00F9BES M30ME-PSC15B-S04G-003480.90 CNY |
|
| Dimension | Ø 30 x 65 mm | Ø 30 x 65 mm | Ø 30 x 44.5 mm |
|---|---|---|---|
| Style Housing | M30x1.5 | M30x1.5 | M30x1.5 |
| Installation | for flush mounting | for flush mounting | for flush mounting |
| Range | 15 mm | 15 mm | 15 mm |
| Switching output | PNP normally open (NO) | PNP normally open (NO) | PNP normally open (NO) |
| Switching frequency | 100 Hz | 100 Hz | 75 Hz |
| Housing material | Brass, Nickel-free coated | Brass, Nickel-free coated | Brass, nickel-plated |
| Material sensing surface | PA 12 | PA 12 | PA 12 |
| Connection | Connector, M12x1-Male, 4-pin | Connector, M12x1-Male, 4-pin | Connector, M12x1-Male, 4-pin |
| Operating voltage Ub | 10...30 VDC | 10...30 VDC | 10...30 VDC |
| Ambient temperature | -25...70 °C | -25...70 °C | -25...70 °C |
| IP rating | IP67 | IP67 | IP67 |
| Approval/Conformity |
CE UKCA cULus WEEE |
CE UKCA cULus WEEE |
cULus CE WEEE |
Only CAD model download is supported
